Xenon Test Chamber
The BGD 860 is a high-performance Xenon Test Chamber designed with modern technology. This instrument uses air-cooled Xenon lamps and a daylight filter to accurately simulate the light test conditions. Through its special design and technical improvements, it can simulate full sunlight in the outdoor environment without tilting.
This Xenon Test Chamber is designed to meet the strict standards for various industries and testing applications. The sample holding area is designed in a rotating manner, so that each sample can receive the same photosynthesis. Its touch-sensitive touch screen display provides the ability to customize test parameters and record data directly to a computer via USB connection.
The use of the BGD 860 Xenon Test Chamber is committed to increasing the accuracy and efficiency of testing, providing reliable and comparable results. Technological advancements such as spray functionality, humidity control capabilities, and automatic measurements make it an important testing tool in various industries.
Xenon Test Chamber Characters
- High-quality Xenon lamps – Xenon lamps imported from the United States are used, which provides high accuracy and repeatability of test results, providing uniform levels of comparability.
- Rotating drum design – The sample holding area is designed to rotate, so that each sample receives the same amount of light. This improves the accuracy of the test.
- Unique photoluminescence control – “Closed-Loop” control system is capable of automatically adjusting the brightness of the lamps over time, so that the irradiance remains stable.
- Versatile filters – Three types of filters, Daylight, Window Glass, and Extended UV, can create the perfect lighting environment depending on the testing needs.
- Custom test programs – Each user can set up to 10 custom programs according to their needs and save 6 programs.
- Testing Segments – Each test program can have up to 10 separate segments, providing comprehensive measurement control.
- Test chamber humidity control – A system is provided to accurately monitor and automatically adjust the humidity of the working chamber.
- Photosynthetic energy monitoring system – The photosynthetic energy available to the sample can be calculated and the test results can be accurately recorded.
- Spray function – Spray water on samples to perform moisture or humidity tests, and customize the soaking time and interval.
- Easy measurement adjustments – Users can adjust the irradiance and black panel temperature (BPT) themselves.
- High-precision temperature sensor – Pt100 temperature sensor can accurately monitor BPT, BST (Black Standard Temperature) and working chamber temperature.
